Applications
The one-pass UV printer finds extensive use in a range of industrial printing applications, including signage boards, appliance parts, promotional products, corrugated boards, imitation building materials, plastic products, toys, sporting goods, clothes tags, and tools, among others. It serves as an ideal solution for printing multiple colors on flat or semi-flat substrates for both short and long runs, ensuring quick delivery times.




Outstanding Features
- The intelligent digital inkjet printing system enables direct printing of images from a computer, featuring an automatic materials feeding platform and a user-friendly machine operation interface for efficient production.
- Utilizing digital single-pass inkjet printing technologies, the one-pass UV printer achieves printing speeds ranging from 25 to 50sqm/minute, facilitating rapid delivery of small and medium orders for customized production, thereby saving time and labor.
- Environmentally friendly UV-curable ink is suitable for printing on a variety of substrates, such as foamboard, glass, wood, acrylic, corrugated boards, and imitation building materials.
- Characterized by fast order changing speed, the printer eliminates the need for plate making and ink washing, making it suitable for printing both small-sized objects and large boards in a single pass.
- Variable printing technology supports the incorporation of unique QR codes on each print, such as anti-counterfeiting codes and product security codes, for traceability purposes.
Specification
|
Model |
Single pass uv printing line |
|
|
Printhead type/QTy |
Industrial Piezo; 40/80 |
|
|
Print platform |
Conveyor belt with vacuum suction |
|
|
Media width |
1250mm |
|
|
Print width |
Max.1220mm |
|
|
Colors configuration |
C M Y K, W as option |
|
|
Print Speed* |
High speed |
50m/minute |
|
High precision |
25m/minute |
|
|
Ink Type |
UV Curable ink |
|
|
Substrates type |
Corrugated board, foamboard, wood panel, imitation building materials |
|
|
Substrate thickness |
1.5-50mm |
|
|
Data processing |
Variable data processing |
|
|
Pretreatment options |
Corona, Plasma, Flame, Cleaner |
|
|
Human machine interface |
Touch Screen |
|
|
Printer Power |
Single Phase AC220V, 16KW |
|
|
Printer Dimensions |
900x200x180cm(LWH) |
|
