Outstanding Features
1. The Driving Mechanism:
To ensure a smooth printing process and avoid media distortion, a high-quality conveyor belt with a vacuum suction system and an automatic anti-deviation feature is implemented to firmly retain both flexible and rigid materials on the printing platform.
2. The LED Curing Technology:
To minimize power consumption and reduce heat damage on various materials, our printer adopts an advanced LED UV curing system.
3. Loop Control:
By implementing a loop control mechanism, the Digital UV Printer ensures smoother and more efficient media feeding and collection. This technology allows for stable control during the printing process and contributes to a productive printing experience.
4. Printhead:
Equipped with cutting-edge P.H. technology, which enables it to produce large quantities of prints quickly. It can reach a speed of 180sqm when in production mode and up to 260sqm when set to draft printing mode. The advanced printing technology includes grey-scaling and variable ink drops that range from 6/12/18pl.
5. Maglev Technology:
Incorporating Maglev driving system and metal encoder raster at the X-axis, the technology guarantees dependable motion control and precise placement of ink droplets at unparalleled printing speeds. With a 30% reduction in ink consumption compared to obsolete technologies.
Parameter
|
Model |
Beyonder Hybrid5200 |
|||
|
Print size |
51 00mm |
|||
|
Thickness |
34mm |
|||
|
P.H. Type |
Konica1024a |
Konica1024a |
||
|
P.H. QTY |
8,10,12,15,16 |
16,24,32 |
||
|
Print Speed |
720dpi |
200m2/h |
720dpi |
260m2/h |
|
1080dpi |
140m2/h |
|||
|
1080dpi |
180m2/h |
|||
|
1440dpi |
90m2/h |
|||
|
Color Configuration |
2(CMYK)+2W+2V |
4(CMYK) |
||
|
3(CMYK )+2W |
||||
|
4(CMYKLcLm) |
||||
|
3(CMYK)+3W |
||||
|
RIP Software |
Caldera GrandRip Photoprint Server |
|||
|
Dimensions |
6.5 x 1.8 x 1.55m |
|||
P.H. Configuration
Applications
