Outstanding Features

Driving System:

The Hybrid Flatbed Printers are equipped with a top-notch conveyor belt that includes sectional vacuum suction and an automatic anti-deviation mechanism. This ensures that both flexible and rigid materials are securely held on the printing platform, preventing any skewing or wrinkling of the media.

LED Curing:

The printer uses an LED UV curing system that conserves energy and reduces heat on different media types, making it suitable for a wide range of materials.

Loop Control:

With a loop-controlled media feeding and take-up system, the Hybrid Flatbed Printers provide stable and efficient handling of materials during both feeding and collection processes.

Printhead:

Featuring cutting-edge printheads, the printer is capable of high-volume production. It can achieve print speeds of 180 sqm in production mode and up to 260 sqm in draft mode. The advanced grayscale printing technology offers variable ink drops of 6/12/18pl.

Maglev Tech:

Incorporating a Maglev driving system and a metal encoder raster on the X-axis, the Hybrid Flatbed Printers ensure precise and smooth movement, along with accurate ink drop placement at very high printing speeds. This technology reduces ink consumption by 30% compared to older systems.
